BM100

Production information


  • High usability
    • Optimized optical configuration and smooth and efficient airflow design for 3D laser cutting environments for thin sheet cutting and other customization needs in different applications.
  • Lightweight integrated design
    • Lightweight integrated design, the body only weighs about 3.5KG, reducing the robot load.
  • Highly sealed
    • Robust seal, modular slim nozzle design reduces workpiece interference, reduces downtime and extends service life.
  • Built- in function built-in
    • The built-in follow-up unit of the product automatically drives the focus follower module to automatically change position within a certain range.
  • Highly dust-proof
    • A protective mirror is added to the collimating mirror to prevent dust from falling directly onto the collimating lens and destroying the collimating lens.



  • Power level：≤3.3KW
  • Collimation lens focal length：100mm
  • Focusing lens focal length：125mm
  • Nozzle hole specifications：①single layer; ② double layer
  • Optical fiber interface：①QBH; ② QD
  • Nozzle aperture：0.8 mm; 1.0 mm; 1.2 mm; 1.5 mm; 20 mm; 2.5mm; 3.0 mm
  • Clear aperture：28mm
  • Upper protective mirror specification：φ24.9mm*1.5mm
  • Lower protection mirror specification：φ27.9mm*4.1mm
  • Manual focus range：+7~-9mm
  • Follow-up stroke：20mm
  • Auxiliary gas pressure： ≤25bar
  • Weight：~3.5kg
