BT200

Production information


  • 3D cutting
    • The fiber optic head for low power 3D cutting applications can withstand 800W.
  • High cutting quality
    • The overall optimized optical focusing system, the design of the annular gas path and the helium gas path, and the fine adjustment of the focus position make the 3D laser processing more excellent.
  • Ultra-slim nozzle design
    • Modular, ultra-slim nozzle design reduces workpiece interference.
  • Compact structure
    • The weight is extremely clear and the volume is small, which reduces the robot load requirement and improves the cutting speed and quality.





  • Power level：≤800W
  • Collimation lens focal length：75mm
  • Focusing lens focal length：①125mm; ②150mm
  • Optical fiber interface：①QBH; ②QCS24; ③QCS30
  • Nozzle aperture：①0.8 mm; ②1.0 mm; ③1.2 mm; ④1.5 mm; ⑤2.0 mm; ⑥2.5 mm; ⑦3.0 mm
  • Clear aperture：21mm
  • Protective mirror specifications：φ27.9mm*4.1mm
  • Auxiliary gas pressure：≤20bar
  • Weight：~1.2kg
