BT210S FC
- High adaptability
- With a variety of fiber optic interfaces such as QBH and QCS , it can be adapted to various mainstream lasers.
- Excellent design
- Optimized optical configuration and smooth and efficient airflow design significantly improve cutting quality and efficiency.
- Slender nozzle design
- Modular, elongated nozzle design reduces workpiece interference.
- Compact structure
- Extremely lightweight and compact, it reduces the robot's load requirements and improves cutting speed and quality.
- Power level:≤1500W
- Collimation lens focal length:①75mm; ②100mm
- Focusing lens focal length:①100mm; ②125mm
- Nozzle hole specifications:① single layer; ② double layer; ③ non-standard
- Optical fiber interface:①QBH; ②QCS
- Nozzle aperture:0.8mm; 1.0mm; 1.2mm; 1.5mm; 2.0mm; 2.5mm; 3.0mm; 3.5mm; 4.0mm; 4.5mm; 5.5mm
- Clear aperture:25mm
- Collimation protection mirror Specifications:φ24.9mm*1.5mm
- Focus protection mirror Specifications:φ27.9mm*4.1mm
- Auxiliary gas pressure:≤25barWeight ~2.3kg
Description
- High adaptability
- With a variety of fiber optic interfaces such as QBH and QCS , it can be adapted to various mainstream lasers.
- Excellent design
- Optimized optical configuration and smooth and efficient airflow design significantly improve cutting quality and efficiency.
- Slender nozzle design
- Modular, elongated nozzle design reduces workpiece interference.
- Compact structure
- Extremely lightweight and compact, it reduces the robot's load requirements and improves cutting speed and quality.
Specification
- Power level:≤1500W
- Collimation lens focal length:①75mm; ②100mm
- Focusing lens focal length:①100mm; ②125mm
- Nozzle hole specifications:① single layer; ② double layer; ③ non-standard
- Optical fiber interface:①QBH; ②QCS
- Nozzle aperture:0.8mm; 1.0mm; 1.2mm; 1.5mm; 2.0mm; 2.5mm; 3.0mm; 3.5mm; 4.0mm; 4.5mm; 5.5mm
- Clear aperture:25mm
- Collimation protection mirror Specifications:φ24.9mm*1.5mm
- Focus protection mirror Specifications:φ27.9mm*4.1mm
- Auxiliary gas pressure:≤25barWeight ~2.3kg
