BM109

Production information


  • Cost-effective
    • Adaptable to low-power semiconductor and fiber laser market needs, for ferrous and non-ferrous metals.
  • Efficient cooling
    • Both the collimating mirror and the focusing mirror are water-cooled for long-term stability and long life.
  • Excellent welding results
    • Optimized optical design for high speed, high quality low power laser welding.
  • Extensive expansion modules
    • Modules such as expandable welds or locating functions make it easy to automate welding.
  • High-quality airflow design
    • With a smooth and efficient fluid structure design for the best weld pool protection.






  •  Power level：≤1.5KW
  • Collimation lens focal length：①100mm
  • Focusing lens focal length：①125mm; ②150mm
  • Nozzle hole specifications：① single layer; ② double layer; ③ non-standard
  • Optical fiber interface：①QBH;
  • Nozzle aperture：0.8mm; 1.0mm; 1.2mm; 1.5mm; 2.0mm; 2.5mm; 3.0mm; 3.5mm; 4.0mm; 4.5mm; 5.0mm
  • Focused light aperture：26mm
  • Collimation protection mirror specifications：φ24.9mm*1.5mm
  • Focus protection mirror specifications：φ27.9mm*4.1mm
  • Auxiliary gas pressure：≤25bar
  • Weight：~3kg
