BM111

Production information


  • Optimize the design structure
    • Modular, easy to maintain and reduce downtime.
  • Multiple protective lenses
    • 3 protective lenses for efficient protection of collimated focusing lenses.
  • Durable
    • 2-way optical water cooling, effectively extending the continuous working time.
  • Highly dustproof
    • IP65 dustproof, patented mirror cover, dustproof and dead angle.
  • Auto focus
    • Automatic focusing, reducing human intervention, focusing speed 10m/min, repeatability 50μm.
  • High speed cutting
    • 12mm thick SUS304 cutting speed 0.7m / min @3000W, 12mm thick Q235 cutting speed 1.2m / min @3000W.





  • Power level ≤3.3KW
  • Collimation lens focal length ①100mm
  • Focusing lens focal length ①125mm; ② 155mm; ③ 200mm
  • Nozzle hole specifications 1 single layer; 2 double layer;   3 non-standard
  • Optical fiber interface ①QBH; ② QDNozzle aperture 0.8mm; 1.0mm; 1.2mm; 1.5mm; 2.0mm; 2.5mm; 3.0mm; 3.5mm; 4.0mm; 4.5mm; 5.0mmClear aperture 28mmCollimation protection mirror specifications φ24.9mm*1.5mm
  • Focus protection mirror specifications φ27.9mm*4.1mm
  • Auxiliary gas pressure ≤ 30bar
  • Weight ~5.7kg
