BW210

Production information

BW210

1.5KW low power welding head



Fast welding speed and good quality

Low power deep penetration welding




  • Cost-effective
    • It can be adapted to the needs of low-power semiconductor and fiber laser markets for ferrous and non-ferrous metals.
  • Efficient cooling
    • Both the collimating mirror and the focusing mirror are water-cooled, which can work stably for a long time and prolong the service life.
  • Excellent welding results
    • Optimized optical design for high speed, high quality low power laser welding.
  • The expansion module is rich
    • Modules such as expandable welds or locating functions make it easy to automate welding.
  • High quality airflow design
    • The smooth and efficient fluid structure design provides the best molten pool protection.





  • Power level：laser power ≤1.5KW
  • Clear aperture：26mm
  • Protective mirror specifications：Φ24.9mm × 1.5mm
  • Auxiliary gas pressure Recommended
    • Air knife：6bar
    • Welding protective gas：25L / min
    • Weight：2.6kg (with CCD lens module)
  • Optional module
    • Weld seam tracking system：realize robot automatic tracking weld
