BT250WL

Production information






  • The collimation and focusing adopt double water cooling design to ensure efficient and stable welding of the welding head for a long time.
  • Optimized optical configuration and smooth and efficient airflow.
  • The use of a drawer type mirror holder makes the focusing mirror and the protective lens easy to replace.
  • A variety of fiber optic interfaces for adapting to a wide range of lasers.
  • The fiber has two configurations of vertical incidence and horizontal incidence.





  • Power level：≤6KW
  • Applicable laser reflection angle：≤0.22
  • Wavelength range：900nm-1100nm
  • Clear aperture：48mm
  • Protective mirror specifications：Φ50.8mm*2mm
  • Auxiliary gas pressure：≤10bar
  • Processing end：Optional coaxial nozzle or air knife and side blow
  • Weight：>3.0kg
