AK190 TC

Production information


  • High withstand power
    • With a direct water-cooled copper mirror, the lens has a long service life and a maximum power of 6 kW.
  • Efficient cooling
    • The double water-cooled structure design protects the mirror base and the laser head body with a water-cooled interface to extend the continuous working time.
  • Highly compatible
    • A variety of fiber optic interfaces are available to accommodate a variety of lasers.
  • Customized focal length
    • Rich collimation, focus configuration, can be customized to meet the needs of different customers.





  • Clear aperture：34.5mm
  • Protective lens：Φ30mm*5mm
  • Internal pressurized air pressure：≤ 2bar
  • Auxiliary gas pressure：≤5bar
  • Weight：5kg
